Metal cable gland reducer PG Thread Cable Gland Reducer And Enlarger metal connector metal joints PG48 PG36 PG29 PG21 PG13.5

Cable glands are used to securely seal cables of varying diameters, providing protection against dust and water ingress. They are suitable for use with all types of power, control, instrumentation, data, and telecommunication cables. Acting as sealing and termination devices, they ensure that the integrity of the enclosure into which the cables enter is fully maintained.
Material: UL-approved Nylon PA66 or Nickel-plated Brass
Seal: Nitrile Rubber (NBR) or EPDM Rubber
IP Rating: IP68 (with seal and O-ring)
Operating Temperature: Static: -40°C to 100°C (Momentary heat resistance: 120°C); Dynamic: -20°C to 80°C (Momentary heat resistance: 100°C)
Certifications: CE, RoHS, SGS
Colors: Black, Grey (Natural Nylon); other custom colors available

• Made of flame retardant PA66 (UL94-V0), temperature range: -40℃~+120℃, acid & alkali resistant, anti-aging, no crack under outdoor long-term UV exposure.
• NBR rubber sealing ring: oil-proof, flexible, tight cable clamping for stable IP rating.
• Standard IP65, enhanced type up to IP68; fully dustproof & waterproof against splash & temporary immersion.
• Strain relief flexible tail prevents cable bending crack, avoid wire insulation damage from frequent pulling.
• Adjustable sealing for a range of cable diameter, PG & Metric M thread full size from PG7 to PG63 for option, reduce stock SKU.
• Split hexagonal lock nut, easy cabinet mounting, reusable for maintenance without cabinet damage.
• Self-extinguishing flame retardant housing, prevent fire spread inside electrical cabinet.
• Widely used in energy storage, PV cabinet, LED lamp, pump & industrial machine; black & white color match different enclosures.

SMICO Cable Gland Applications :

• New Energy Industry
• Electrical & Automation
• Lighting & Outdoor Lamp
• Machinery Equipment
• Security & Communication

01. How many employees does your factory have?

We have over 130 employees, covering the entire production chain.

02. What cable diameter can each size fit?

Every gland matches a certain cable range via inner rubber seal. Example: PG9 fits 4~8mm cable; PG16 fits 6~12mm. Check dimension sheet for exact range.

03. What’s the difference between standard type & flexible strain-relief tail type?

Standard straight type for fixed wiring; corrugated flexible tail design prevents cable bending crack, ideal for frequently bent wires on servo motors & automation equipment.

04. How do I place an order?

Please send your purchase order to us via email, and we will send you a quotation and a pro forma invoice.
