Heavy Duty Connector 6pin 16A Quick Cage-Clamp Push in HE-006-MS rectangular connector 09330062616
- Part:
- SO-HE-006-MS
- Number of contacts:
- 6
- Rated current:
- 16A
- Rated voltage conductor:
- 500V
- Product Certification:
- UL CUL CE ROHS DMT IEC-61984
- Order No.:
- 09330062616
- Packaging Details:
- Standard Export Cartons
- Delivery Time:
- Within 7 Days
- Payment Terms:
- L/C, T/T, Western Union, Paypal
- Supply Ability:
- 100000 pcs per month
Heavy Duty Connector 6pin 16A Quick Cage-Clamp Push in HE-006-MS rectangular connector 09330062616
Heavy Duty Connector Cage-clamp terminal 6pin male insert- -SMICO Connectivity 6pin HE-006-MS ,16A used for industrial robot ,various harness field
6 Poles+PE,16A,Cage-clamp male insert
| Inserts | Suitable Shell:6BHood/Housing |
| Number of contacts | 6 |
| Electrical data acc. to EN 61 984 | |
| ---Rated current | 16A |
| ---Rated voltage conductor | 500V |
| ---Rated impulse voltage | 6kV |
| ---Pollution degree | 3 |
| ---Pollution degree 2 also | 16A 400/690V 6kV 2 |
| Rated voltage acc. to UL/CSA | 600V |
| Insulation resistance | ≥1010Ω |
| Material | polycarbonate |
| Limiting temperatures | -40℃...+125℃ |
| Flammability acc. to UL 94 | V0 |
| Mechanical working life(mating cycles) | ≥500 |
| Contacts | |
| Material | copper alloy |
| Surface | hard-gold plated |
| hard-silver plated | |
| Contact resistance | ≤1mΩ |
| Screw terminal | |
| ---Wrie gauge | 0.14-2.5mm2 |
| ---AWG | 26-14 |
| ---Tightening/Test torque | 0.5N·m |
| ---Stripping length | 7.0mm |
SMICO heavy duty connector can match the following interchangeable.
The hood and housing for H6B .
| Suppier | Plug insert | Socket insert |
| SMICO | SO-HE-006-M | SO-HE-006-F |
| H | 09330062601 | 09330062701 |
| ILME | CNEM 06 T | CNEF 06 T |
| TE | ||
| LAPP EPIC | 10.1900 | 10.1910 |
| PHOENIX | 1648115 | 1648128 |
| MOLEX | ||
| WEIDMULLER | HDC HE 6 MS | HDC HE 6 FS |
| WIELAND | 70.310.0602.0 | 70.300.0602.0 |
| AMPHENOL |
SMICO heavy duty connector
-
Compatible with other brands
-
accept OEM /ODM
-
accept customized colour : like blue ,black
-
The popular parts in stock , delivery time fast
-
Export Packing : Packing for each items respectively or packing for full one set
SMICO Heavy duty connectors Applications :
- Machinery
- Automation
- Robotics
- Rail
- Energy Distribution
- Renewable Energy
- Construction Machinery
- Professional Light and Sound
What products does the SMICO heavy duty connector consist of ?
The HDC portfolio consists of:
1. Insert : 1 to 216 pins for crimping terminal ,screw , cage termination .
2.Hoods, housings and bases: available in different protection degrees IP65, IP67, IP68 and IP69k
3.Contact systems: ranging from 5A to 650A in screw, crimp and cage clamp termination
4.Cable gland : according your cable range
