Energy Storage Connector Plug Connection Form

1.energy storage connector Threaded plug connection

This is a connection form often used in some connector plugs with larger contact parts and working in strong vibration environments. After the connection is completed, a fuse or nut can be installed to prevent loosening. This connection form is reliable to use, but the connection and disconnection speed is slow.

2.battery storage connector Plug bayonet connection

This is a reliable and fast connection and disconnection form. Most electrical connectors with a bayonet 121 connection form have a visual display of correct connection and locking, which can be observed from the small hole on the side of the electrical connector connection nut.

3.storage connector Plug plug-in connection

This is a multi-purpose connection form. When the plug and socket of the electrical connector are connected and disconnected, their moving direction is usually reciprocating linear motion, without twisting and rotation, and only a small working space is required to complete the connection and disconnection. Common plug-in connections have two structures: ball bearings or pins. Because this connection form has no mechanical labor-saving mechanism, once it is misplugged, the mechanical resistance will increase significantly and can be discovered in time.

4 Energy storage connector plug cabinet connection method

This is an electrical connector used on some equipment that needs to be blindly connected close to the frame, which can make the electrical equipment lighter and smaller, easier to maintain and more reliable. This connection form makes it impossible for the operator to feel the connection, and a precise positioning device must be designed to avoid forcing the wrongly inserted connector plugs to be connected together, making it impossible to insert the wrong plug. The connector plug usually adopts a floating or elastic contact design structure to ensure its correct connection.
