What Are The Correct Operating Methods For Cold Pressing Needle Crimping Machine?

contact crimper is a device widely used in the fields of electricity, communications, electronics, etc., mainly used to crimp wires and terminals. In order to ensure the safety and effectiveness of the operation, it is very important to master the correct operation method. This article will introduce the correct operation steps of d sub contact crimper in detail.

1. Preparation before operation

1. Check the equipment

Before using contact crimping tool, first check whether the various components of the equipment are intact. Specifically include:

Check whether the crimping machine and the die are installed firmly.

Check whether the power supply voltage meets the regulations (usually 220V).

Check whether the foot switch and the power socket are plugged in firmly.

2. Prepare materials

Fix the terminal roll and lead the terminal into the die through the guide plate.

Select the appropriate crimping terminal according to the wire specifications to be crimped.

3. Adjust parameters

Adjust the crimping height and manually operate the test terminal to ensure that the crimping effect meets the requirements.

2. Normal operation

1. Start the equipment

Press the operation switch to the working position, and the motor starts to run.

2. Place the wire

Place the wire in the appropriate position of the terminal crimping part, and ensure that the crimped terminal is located in the middle of the upper and lower die knives.

3. Crimping

Step on the foot switch, the main machine slider rushes down, and the crimping of the wire and the terminal is completed.

Release the foot switch, the slider automatically returns to its original position, and the next terminal is sent to the crimping position.

4. Repeat the operation

Repeat the above steps of placing the wire and crimping to achieve continuous crimping of the wire and the terminal.

3. Precautions during operation

1. Safety protection

Operators must wear appropriate protective equipment, such as protective shoes, safety helmets, insulating gloves, etc.

During operation, it is strictly forbidden to put hands, feet or other parts of the body into the working area of ​​the mold or press.

2. Parameter adjustment

Before debugging various parameters, the power switch of the crimping machine must be turned off.

Confirm whether the crimping head has been disassembled and check whether the power supply voltage is stable.

3. Abnormal handling

If abnormal noise or other abnormal phenomena occur during operation, the operation must be stopped immediately and the cause must be checked.

During operation, you must never leave the site.

4. End of work

After the work is finished, cut off the power supply and keep the machine clean.

When disassembling the crimping head, it must be disassembled in the required direction in sequence, and it must not be disassembled forcibly.

Mastering the correct operation method of the manual crimping machine can not only improve work efficiency, but also ensure the safety of the operator. In actual operation, strictly follow the operating procedures and regularly inspect and maintain the equipment, which can effectively extend the service life of the equipment and ensure the smooth progress of production.

Through the introduction of this article, I hope to help the majority of operators better master the operating skills of the manual crimping machine and improve work quality and safety.
