SMICO RJ45Connector

Publish Time: 12/04 2021 Author: Site Editor Visit: 1328

SMICO RJ45 is a connector that features a future-proof design for 10 Gigabit Ethernet. The connection is made reliably and quickly using proven insulation displacement terminal technology. The insulation displacement terminals are designed for rigid and flexible conductors with an extremely broad range of wire cross-sections. Cables with diameters from 4.5 to 9 mm are securely fixed in place in the connector with a newly developed cable gland. This allows users to connect all customary Ethernet cable types with this one RJ45 connector type. Thanks to its compact design, the rugged and industry-standard IP 20 model is also suitable for multi-port RJ45 jacks. In addition to the IP 20 models, all known IP 65/67 PushPull types up to Han 3A are now available with this new insert
